Metal Cladding
GT Sinusoidal Cladding System
GT sinusoidal cladding system is intended for building façade or roofing system with/without back ventilation. The convex outline of corrugated panel gives unique aesthetic effect to the building. As light and shadow play over it, the building shows different visual effect.
For more information
GT sinusoidal cladding system is intended for building façade or roofing system with/without back ventilation. The convex outline of corrugated panel gives unique aesthetic effect to the building. As light and shadow play over it, the building shows different visual effect.
Sinusoidal Cladding System
1.Reinforcement for the trays
2.Subconstruction
3.Tray
4.Subconstruction for sinusoidal sheet
5.Decoupling
6.Insulation
7.Insulation
8.Sinusoidal sheet 18/76
9.Fastening element
Material Options
Materials with excellent anti-corrosion performance and long service life, e.g., pre-painted aluminium, are recommended for the system to achieve a service life of more than 50 years.
